Products Description
Heavy-duty applications require equipment that is powerful and durable, and diesel forklifts are a great example of such equipment. They have a reputation for being robust and dependable, which is why they are widely used in various industries.
One major advantage of diesel engines is their exceptional torque. They possess the ability to effortlessly propel large loads, making them ideal for tackling challenging landscapes such as steep inclines or uneven terrain. This torque-driven power allows for efficient and swift movement of heavy objects.
Gas engines, in contrast to diesel engines, have lower fuel efficiency and need to be refueled more frequently due to their shorter operating time on a tank of fuel.
Diesel engines are renowned for their durability and reliability. With their robust components and adherence to strict maintenance schedules, these engines are built to withstand the toughest conditions. In fact, they often outlast other types of forklifts, making them a preferred choice for harsh environments.
Diesel engines are renowned for their ability to generate immense power, especially when it comes to performing heavy-duty tasks like lifting and transporting heavy loads. This makes them the perfect choice for applications where raw power is a necessity. Their high torque output and reliability ensure that they can handle even the toughest of jobs with ease. Whether in industrial or agricultural settings, diesel engines are a go-to source of power for those who demand maximum performance.
When it comes to industrial and commercial applications, diesel forklifts have proven to be both reliable and powerful. These robust machines are capable of handling heavy-duty operations with ease, thanks to their high torque, fuel efficiency, and durability. Choosing a diesel forklift means opting for a reliable and long-lasting solution that can efficiently carry out demanding tasks. With their impressive capabilities, these forklifts are an ideal choice for industries that require reliable and powerful equipment.


Forklift special tire, large pattern, strong grip.

To prevent foreign objects from hitting the sides, a concave refueling cover is implemented. This design ensures enhanced protection by deflecting any potential impact.

To enhance your rearward view, adjust your rearview mirror to a wider angle.
Optional engine
To cater to different tonnage needs, various types of engines can be chosen. The selection of engines depends on the specific requirements of the vessel and its capacity. Hence, different engines may be chosen to power a small boat as compared to a large cargo ship. By selecting the appropriate engines, vessels can operate efficiently and effectively, thereby achieving optimal performance and productivity.
XINCHAI: C490BPG-30,A495BPG-510A,4D27G31.4D30G31
NISSAN:K21/LPG.K25/LPG
ISUZU:C240PKJ-30,4JG2PE-01
YANMER:4TNE98.TNV94L
MITSUBISHI:S4S-455
| Model | FD20J | ||||
| 1 |
Features |
Power type | kg | Diesel | |
| 2 | Rated load | mm | 2000 | ||
| 3 | Load center distance | mm | 500 | ||
| 4 | Lift height | mm | 3000 | ||
| 5 | Free lift height | mm | 190 | ||
| 6 | Fork size | LxWxT | mm | 1070x122x40 | |
| 7 | Mast tilt angle | FR/RR | 6//12 | ||
| 8 | Minimum turning radius | mm | 2245 | ||
| 9 | Height of overhead guard | mm | 2090 | ||
| 10 | Overhang(FR) | mm | 476 | ||
| 11 |
Pertormance |
Maximum travel speed | Full load | km/h | 19 |
| 12 | Maximum lift speed | Full load | mm/s | 530 | |
| 13 | Maximum drawbar pull | Full load | KW | 17 | |
| 14 | Gradeability | % | 20 | ||
| 15 |
Dimensions |
Overall length | Without forks | mm | 2535 |
| 16 | Overall width | mm | 1150 | ||
| 17 | Fork height at maximum lift(with backrest) | mm | 4020 | ||
| 18 | Mast height | mm | 1995 | ||
| 19 |
Chassis |
Tires |
Front wheel | 7.00-12-12PR | |
| 20 | Rear wheel | 6.00-9-10PR | |||
| 21 | Wheelbase | mm | 1600 | ||
| 22 | Self weight | Without load | kg | 3400 | |
| 23 |
Drive |
Battery | Voltage/capacity | V/Ah | 12/80 |
| 24 |
Engine |
Model | AK-C240PKJ-30 | ||
| 25 | Rated output | kw/r.p.m | 34.3~ 36.5/2500 | ||
| 26 | Rated torque | Nm/r.p.m | 137.7/1800 | ||
| 27 | Fuel tank capacity | l | 60 | ||
| 28 | Transmissions(FWD/RWD) | 1/1 electro-hydraulic directional valve | |||
| 29 | Operating pressure | Mpa | 18.5 | ||
