Product display
- Model:
FD35S
- Load capacity:
3500kg
- Lift Height:
3000-6000mm
- Fork Length:
1220-2200
- Load center:
500mm
- Engine:
XINCHAI/ISUZU/MITSUBISHI
Product advantages
The second level of shock absorption is formed by four shock pads situated between the integrated roof guard frame and the frame, while the full suspension seat works effectively to reduce driver fatigue. These features ensure a comfortable and smooth ride for the operator.
The off-road tire used for driving is designed with deep and wide patterns for optimal performance on rough terrain. Its suitability for challenging road surfaces makes it ideal for exploring off-road routes, enabling smooth navigation through difficult terrains.
The cooling system is equipped with a counterweight opening to enhance the dissipation of heat and increase the area for heat dissipation. This leads to a better heat dissipation effect, making it suitable for continuous operations in environments as hot as +43 degrees Celsius. It is important to note that the generated content has been rearranged and does not follow the same structure as the original text.
To be in compliance with Euro 5 and EPA emission regulations, it is necessary to enhance the power of the vehicle. By making the engine more powerful, it becomes capable of meeting the stringent emission requirements set by these regulatory bodies. Thus, it is essential to focus on improving the power output of the engine to ensure it adheres to the Euro 5 and EPA emission standards.
physical display
Standard Equipment >>>
Option >>>
our service
OEM
One Stop Solution
24-hour service
Technical Guidance
Two-year warranty
Except for wearing parts, reissue parts within the warranty【Support the following courier reissue 】
About us
market/market scope
Our products are widely concerned and favored by domestic and foreign customers for their beautiful appearance, high-quality and comprehensive services, safe, reliable and cost-effective, and have been successfully exported to more than 100 countries and regions around the world.
Certificate/Our honor
In terms of quality assurance, we strictly follow CE/ISO/other patent standards. Adopt a full set of industry-leading testing equipment to ensure product quality and good reputation.
logistics/payment service
Payment
Online trade assurance order, all is up to you.
More payment terms could be provided (T/T,PAYPAL, WESTERN UNION)
|
Model |
|
FD35-S |
||
|
Characteristics |
Driving Mode |
|
Diesel |
|
|
Capacity |
kg |
3500 |
||
|
Load Centre |
mm |
500 |
||
|
Lift Height |
mm |
3000 |
||
|
Mast Tilt Angle (F/R) |
deg |
6/12 |
||
|
Front Overhang |
mm |
590 |
||
|
Wheelbase |
mm |
1850 |
||
|
Tread (F/R) |
mm |
1300/1205 |
||
|
Performance |
Service Brake |
|
Hydraulic |
|
|
Parking Braking |
|
Mechanical |
||
|
Lift Speed (Full Load) |
mm/s |
420 |
||
|
Descent Speed |
mm/s |
full load <600,no-load> 300 |
||
|
Running Speed (Without Load) |
km/h |
22 |
||
|
Max Gradeability |
% |
16 |
||
|
Power and transmission |
Engine |
Model |
|
A498BPG |
|
Manufacturer |
|
XINCHAI |
||
|
Rated Power |
Kw/r |
45/2500 |
||
|
Rated Torque |
Nm/r |
193/1600-1800 |
||
|
CC |
L |
3.168 |
||
|
Optional |
|
XINCHAI,ISUZU,MITSUBISHI |
||
|
Battery |
V/Ah |
12/80 |
||
|
Tyre type |
|
Pneumatic |
||
|
Front tyre |
|
14-17.5-16PR |
||
|
Rear tyre |
|
10-16.5-12PR |
||
|
Others |
Service Weight |
kg |
4950 |
|
|
Fork size |
TxWxL |
mm |
50x122x1070 |
|
|
Length (Without Fork) |
mm |
2980 |
||
|
Wide |
mm |
1650 |
||
|
Mast height |
mm |
4350 |
||
|
OverheadGuard height |
mm |
2250 |
||
|
Min. Turning Radius |
mm |
2930 |
||
|
Min. Ground Clearance |
Mast |
mm |
220 |
|
|
Wheel base |
mm |
350 |
||
