Products Description
Transmission system
The implementation of a three-stage power shift transmission is achieved by utilizing modern micro-electronic control techniques. This technology allows for the automatic and seamless shifting of gears, maintaining a constant power flow without any manual intervention from the driver. By incorporating a transmission proportional control valve, the transmission system is able to deliver smooth shifts, thereby enhancing the overall driving experience. This advanced system ensures a disruption-free operation, enabling the driver to focus on other aspects of the driving task.
Repair and maintenance processes are made easier and more convenient with the inclusion of fault display and a diagnostics jack. These features simplify the tasks by providing clear indications of any malfunctions and allowing for quick and easy troubleshooting. Whether it's identifying a faulty component or conducting routine checks, the fault display and diagnostics jack streamline the repair and maintenance procedures, ultimately saving time and effort. These intuitive tools enable technicians to swiftly address any issues, leading to efficient repairs and ensuring the optimal functioning of the system.
Transaxle
In order to satisfy the requirements of continuous operation in harsh conditions and the users' demand for brake maintenance-free performance, a drive axle with heavy-duty wet brakes is designed. This drive axle is specifically engineered to withstand unfavorable conditions and provide reliable operation without the need for frequent brake maintenance.
Electronic control system
CAN-BUS bus control system, stable and safe
Safety assistance system
Our visual astern warning system is both safe and reliable, providing a standard level of performance. Rest assured that you can rely on it to keep your vessel, crew, and cargo secure.
Bridge
The cab of this vehicle is designed with integral tilting and full floating features. It is connected to the frame using special damping rubber that effectively shields noise and vibration. The front of the driver's compartment is designed with a large glass area, and there are no frame connections in the corners, leaving a wide view of the surroundings.
|
Item |
Project Description | Unit |
FD420 |
|
Features |
Rated Load |
Kg |
42000 |
|
Load Center |
mm |
1250 |
|
|
Wheelbase |
mm |
5500 |
|
|
Weight |
Weight |
kg |
53000 |
|
Chassis |
Tire Specs:Front |
|
18.00-25 |
|
Tire Specs:Rear |
|
16.00-25 |
|
|
Tires Qty,front/rear(X-dreve wheels) |
|
4/2 |
|
|
Wheel tread:Front |
mm |
2480 |
|
|
Wheel tread:Rear |
mm |
2880 |
|
|
Dimensions |
Mast/carriage tilt angle(front/rear) |
Degree(°) |
6/12 |
|
Mast height(fork lowering) |
mm |
5040 |
|
|
Mast lifting height |
mm |
4000 |
|
|
Max.height |
mm |
7040 |
|
|
Height to head guard(height to cab) |
mm |
3890 |
|
|
Overall height（with forks) |
mm |
10770 |
|
|
Fork front verticaal sueface to the rear end of the vehicle |
mm |
8170 |
|
|
Overall width |
mm |
3600 |
|
|
Fork dimension |
mm |
2600*320*130 |
|
|
Fork carriage width |
mm |
3160 |
|
|
Mast min ground(with load) |
mm |
350 |
|
|
Wheelbase center min ground(with load) |
mm |
480 |
|
|
Min.turning Radius |
mm |
7730 |
|
|
Travel speed(with load/without load) |
km/h |
22/26 |
|
|
Performance |
Max.lifting speed(with load/without load) |
mm/s |
220/260 |
|
Tractionn |
KN |
240 |
|
|
Gradeability(with load/without load) |
% |
20/20 |
|
|
Engine |
Engine brand/model |
|
Weichai/Cummins |
|
Cylinder No |
6 |
||
|
Others |
Transmission gears(Front/rear) |
|
4/4 |
